Datos del producto:
|
|
| Lugar de origen: | HECHO EN CHINA |
|---|---|
| Nombre de la marca: | Btutest |
| Certificación: | SGS, INTERTEK |
| Número de modelo: | WAW-100S |
|
Pago y Envío Términos:
|
|
| Cantidad de orden mínima: | 1 |
| Precio: | Negociable |
| Detalles de empaquetado: | LC, D/A, D/P, T/T, Western Union, MoneyGram |
| Tiempo de entrega: | 5-8 días laborables |
| Condiciones de pago: | LC, D/A, D/P, T/T, Western Union |
| Capacidad de la fuente: | 3000 juegos por mes |
|
Información detallada |
|||
| Nombre del producto: | Microordenador Servo electrohidráulico UTM Clase 0,5 Silencioso Sin base ISO ASTM WAW-100/300/600/10 | Fuerza máxima (kN): | 100 |
|---|---|---|---|
| Clase de precisión: | 0,5 (doble sensor) | Error de la fuerza: | ≤±0,5% |
| Rango de fuerza: | 1–100 % escala completa | Rango de velocidad de carga de fuerza: | 0,01–3% FS/s |
Descripción de producto
Microcomputer Electro-hydraulic Servo UTM Class 0.5 Silent No Foundation ISO ASTM WAW-100/300/600/1000KN
Character count: 126
| Feature | Product Advantage | Customer Benefit |
| Class 0.5 accuracy + double load sensor | Force error ≤±0.5%, measuring range 1–100% FS | Data accepted globally, pass audits easily, reduce retests |
| Silent & shock‑absorbing integrated oil source | No vibration or loud noise when specimen breaks | Comfortable lab environment, less operator fatigue, no need for soundproof room |
| No foundation required | Ready to use on any flat floor | Save $1000–3000 on construction, machine can be moved anytime |
| Up‑pressure down‑pull structure + button panel | Ergonomic specimen loading, manual speed control | 70% shorter training time, fewer operator errors, higher efficiency |
| Organic glass protective door | Full visibility with safety protection | Great for teaching and demos; prevents debris injury |
| Servo motor control (servo pump/valve) | More stable and energy‑efficient than traditional hydraulic | 30%+ electricity saving, consistent data over long runs |
| Modular integrated design | Oil source and frame combined; easy to disassemble | Small footprint (saves 20–30% space), quick spare part replacement, less downtime |
| Wide model range (100–1000 kN) | 4 models for different specimen sizes | Buy exactly the capacity you need – no waste |
| Multi‑control modes (force/displacement/strain) | Constant rate force, displacement, strain control | Meets ISO 6892‑1 method A1/A2 (strain rate control) |
| Chinese utility model patent | Unique structural design | Differentiates from cheap copies, adds technical trust |
| Standard | Material / Application | Why It Matters |
| ISO 6892‑1 | Tensile testing of metals | Mandatory for Europe, Middle East, Asia |
| ASTM E8/E8M | Tension testing of metals | Required for North American buyers |
| ISO 7500‑1 | Calibration of testing machines (force) | Proves force traceability |
| GB/T 228.1 | Tensile testing (Chinese standard) | For projects using Chinese materials |
| GB/T 7314 | Compression testing of metals | – |
| GB/T 232 | Bend testing of metals | – |
“We can pre‑install test templates for ASTM, ISO, EN, JIS, and other standards upon request. One‑click switch between standards in the software.”
| Parameter | WAW-100S | WAW-300S | WAW-600S | WAW-1000S |
| Max Force (kN) | 100 | 300 | 600 | 1000 |
| Accuracy Class | 0.5 (double sensor) | 0.5 | 0.5 | 0.5 |
| Force Error | ≤±0.5% | ≤±0.5% | ≤±0.5% | ≤±0.5% |
| Force Range | 1–100% FS | same | same | same |
| Force Loading Speed Range | 0.01–3% FS/s | same | same | same |
| Stress Rate Error | ≤±2% | same | same | same |
| Strain Rate Control Range (/s) | 0.00003–0.0005 | same | same | same |
| Strain Rate Error | ≤±2% | same | same | same |
| Displacement Control Range (mm/min) | 0.5–400 | same | same | same |
| Displacement Speed Error | <±2% | same | same | same |
| Max Rising Speed (mm/min) | 350 | 350 | 350 | 350 |
| Max Descent Speed (mm/min) | 750/650 | 750/650 | 750/650 | 750/650 |
| Tensile Space (mm) | 150–700 | 150–700 | 300–900 | 300–900 |
| Compression Space (mm) | 60–600 | 60–600 | 60–650 | 60–650 |
| Upper Platen Size (mm) | Φ150 | Φ150 | Φ200 | Φ200 |
| Lower Platen Size (mm) | 190×200 | 190×200 | 280×300 | 280×300 |
| Clamping Method | Hydraulic | Hydraulic | Hydraulic | Hydraulic |
| Round Specimen Range (mm) | Φ6–30 | Φ6–30 | Φ13–40 | Φ13–40 |
| Flat Specimen Thick (mm) | 0–20 | 0–20 | 0–30 | 0–30 |
| Specimen Clamping Width (mm) | 75 | 75 | 110 | 110 |
| Motor Power (kW) | 2.3 | 2.3 | 3.0 | 3.0 |
| Power Supply | 220V±10% | 220V±10% | 380V±10% | 380V±10% |
| Net Weight (kg) | 1270 | 1270 | 2364 | 2364 |
| Gross Weight (kg) | 1340 | 1340 | 2440 | 2440 |
Quick selection guide:
Standard accessories (included):
Optional accessories:
Service & support:
“We are the direct manufacturer – not a trading company. Factory price, direct technical support, faster spare parts delivery.”
| Scenario | Point | Recommended Model | Key Advantage |
| University materials lab | Teaching needs clear specimen observation; limited space; high safety requirement | WAW-300S | Organic glass door for viewing; no foundation; Class 0.5 for research |
| Third‑party testing lab | High throughput, need accuracy and low downtime | WAW-600S / 1000S | Class 0.5 accuracy; silent design reduces fatigue; modular easy maintenance |
| On‑site construction lab | No foundation, noisy environment, need fast results | WAW-300S | Plug & play; low noise; quick operation |
| Factory incoming inspection | Multiple materials (round bar, flat bar, bolts); different operators | WAW-100S | Easy to learn; hydraulic grip no slippage |
| R&D (new materials) | Need strain rate control (e.g., stress corrosion) | All models | Strain rate as low as 0.00003/s – meets slow strain rate test requirements |
| Vocational training | Frequent student use, need durability and safety | WAW-100S | Organic glass door + button panel – simple and safe |
Case 1 – University in Brazil
Machine: WAW-300S
“The 0.5 accuracy and organic glass door are perfect for our research and teaching. Students can see necking and fracture clearly. No foundation needed – we placed it in a normal classroom. The silent break is a huge plus.”
– Prof. Silva
Case 2 – Third‑Party Lab in Egypt
Machine: WAW-600S
“We test hundreds of rebar samples weekly. The silent shock‑absorbing design means technicians don’t jump when the specimen breaks. Maintenance is easy – we replaced a seal ourselves. The button panel is preferred by our older staff.”
– Lab Manager
Case 3 – Steel Fabricator in Philippines
Machine: WAW-300S
“We used to outsource testing. Now we test on‑site – no foundation, just unpack, plug in, and start. Saved $5000 in outsourcing fees last year. New operators run tests after 30 minutes training.”
– Quality Supervisor
Case 4 – Precast Concrete Plant in India
Machine: WAW-600S
“Hydraulic gripping solved slippage with high‑strength rebar. The machine is much quieter than our old one. Compact footprint fit perfectly into our limited lab space.”
– Plant Manager
Case 5 – Research Institute in Saudi Arabia
Machine: WAW-1000S
“We need very slow strain rate tests for stress corrosion research. This machine’s strain rate control is precise and stable. Class 0.5 accuracy gives confidence in our published data.”
– Senior Researcher
✅Free sample testing– let us prove the accuracy before you pay.
✅Factory direct price– no middleman markup.
✅12 months warranty + lifetime remote support– we stand behind our machine.
✅Quick delivery– 25–35 days for standard models.
✅No foundation needed– save time and money.
��Click “Contact Supplier” nowand tell us:
• What materials/specimens you test (rebar, plate, bolt, etc.)
• Maximum force required (kN)
• Any special standard (ASTM, ISO, etc.)
We will reply within 2 hours with a recommendation and quotation.
“Btutest – your reliable partner in material testing since 2010.”
